Place of Origin:
Shenzhen, China
Brand Name:
ZEROONE-Control
Certification:
CE ROHS
Model Number:
P430/DM430
Document:
Product Overview
The P430 is a newly launched digital stepper motor driver from the company, featuring cutting-edge 32-bit DSP digital processing technology. Its control algorithm incorporates advanced current regulation and frequency conversion technologies, ensuring minimal heat generation, reduced motor vibration, and smooth operation. Users can set any subdivision value between 200-51200 and any current value within the rated current range, meeting the needs of most applications. Thanks to built-in micro-subdivision technology, it achieves high precision even at low subdivision settings, delivering stable performance across low, medium, and high speeds with ultra-low noise. The driver integrates an automatic parameter calibration function that dynamically optimizes operating parameters for different motors, maximizing their performance potential.
Application Areas
Suitable for all kinds of small and medium-sized automation equipment and instruments, such as: engraving machine, marking machine, cutting machine, laser phototypesetting, plotter, CNC machine tool, automatic assembly equipment, etc. It is especially effective in the application of equipment with low noise and high speed.
1. Electrical specifications
|
Explain |
P430 |
|||
|
Least value |
Representative value |
Crest value |
Unit |
|
|
Output |
0.1 |
- |
3.0 |
A |
|
Input power supply voltage |
18 |
24 |
40 |
VDC |
|
Control signal input current |
6 |
10 |
16 |
mA |
|
Control signal interface level |
4.5 |
5 |
28 |
Vdc |
|
Minimum pulse width of input signal |
1.5 |
- |
- |
us |
|
Step pulse frequency |
0 |
- |
200 |
KHz |
|
Insulation resistance |
500 |
|
|
MΩ |
2. Usage environment and parameters
|
Cooling-down method |
Natural cooling or forced air cooling |
|
|
Service environment |
Occasion |
Do not place near other heating devices. Avoid dust, oil mist, corrosive gases, excessive humidity, or strong vibrations. Do not allow flammable gases or conductive dust. |
|
Temperature |
-5℃ ～ +50℃ |
|
|
Humidity |
40 ～ 90%RH |
|
|
Vibrate |
5.9m/s2MAX |
|
|
Storage temperature |
-20℃～80℃ |
|
|
Use altitude |
Below 1000 meters |
|
|
Weight |
116 grams |
|
3. Mechanical installation drawing
